An armored personnel carrier on close acquaintance turned out to be very beautiful and somehow correct in proportion. A clot of pure functionalism multiplied by the crocodile animal plastics.

btr how it is done


Bare bodies, factory workers say “gondola”, come from nearby Vyksa. Already welded, painted and part of the wiring and mechanization of the suspension.

btr how it is done

Shinmontazh. Tightening the tire on the disc, manually.

btr how it is done

Further, the body with bolted wheels, stand on the assembly line.

btr how it is done


Inside the body put the line and install the devices.

btr how it is done

Conveyor. No automation. No robots. All pens. There are no overhead lines, and therefore no pneumatic tools. The only thing I saw was the impact wrench for loosening the wheel nuts. Yes, and that electric, heavy. However, all operations and details are subject to tight controls. Perhaps, therefore, the percentage of complaints is extremely low.

btr how it is done


BTR - fully hydro and gas insulated. On the photo there is a door with a gas analyzer.

btr how it is done


Installation of all sorts of pieces. The enterprise is a military one, so a very tight control was taken behind the photo shoot.

btr how it is done

Conveyor. The cars themselves do not travel, the tape with supports moves under them.

btr how it is done
btr how it is done

Motor and Gearbox KAMAZ, On the motor, two turbines blowing in different sections. Mechanical injection pump. Without EURO.

btr how it is done
btr how it is done

Machines with installed power plants.

btr how it is done

Workshop debugging and adjustment.

btr how it is done
btr how it is done

Then the cars go to the installation of what is ordered. Even the skin material inside is being discussed (Rolls-Royce is resting). In general, the BTR is already full of modifications: floating and non-floating, a communications vehicle, a command and command vehicle (instead of a tower, a hump above the landing compartment) and much more that the customer will order. There is even a pickup.

btr how it is done

In this workshop, all products move under their own power. The main thing is to be attentive, can pin down.

btr how it is done


Various modifications of machines.

btr how it is done
btr how it is done
btr how it is done

All cars are waiting for a test march, this is 100 kilometers with a factory driver, and then another 50 km with a customer representative. And only then, if nothing has fallen off or broken, the products are shipped to the customer.

btr how it is done

Pool. Part of the test march.
And it swims! Not a speed boat, of course. But not "Titanic". Does not sink. It floats and even rolls in turns, like a real ship.

btr how it is done

Out of the water. Looks very impressive.

btr how it is done

After the march, the products are driven to the state acceptance. They check everything. Literally.

btr how it is done

Having plunged into a minibus waiting for us, we moved to the side of the landfill. There also went and bathed BTR. The site is located on the territory of the plant. Not large in size. A standard set of obstacles that the tested equipment passes in a standard and “cool” way. What actually happened.

btr how it is done
btr how it is done
